“Images are for illustrative purposes only. Actual product may vary.”
About
24V COB LED Strip Lights
Our 24V COB LED Strip Lights deliver a seamless, dot-free line of light, making them ideal for both decorative and functional lighting applications. With hundreds of closely packed LED chips, COB (Chip-on-Board) technology provides smooth, uniform illumination that's perfect for under-cabinet lighting, shelving, retail displays, signage, architectural features, and residential or commercial installations.
TEST PRODUCT
8w | Warm, Natural, Cool White
Online Price:
Original price was: R60.00.R54.00Current price is: R54.00. Vat Incl.
Applications & Use Cases
24V COB LED Strip Light Applications & Use Cases
24V COB LED Strip Lights are a versatile lighting solution suitable for both residential and commercial projects. Their continuous, dot-free illumination creates a clean, modern appearance while providing bright, even lighting.
Common applications include:
- Under-cabinet kitchen lighting
- Shelf and display cabinet illumination
- Retail displays and shop fittings
- Architectural feature lighting
- Cove and cornice lighting
- Ceiling recess and bulkhead lighting
- Staircase and handrail lighting
- Wardrobe and closet lighting
- Reception desks and office lighting
- Hotel, restaurant, and bar ambience
- Exhibition stands and trade show displays
- Signage and illuminated lettering
- TV backlighting and entertainment units
- Caravan, motorhome, and marine interiors
- DIY home lighting projects
With their 24V design, COB LED strips are ideal for longer installations where consistent brightness and minimal voltage drop are important. They can also be dimmed using compatible LED dimmers and controllers, making them suitable for both task lighting and mood lighting.
Frequently Asked Questions
24V COB LED Strip Light FAQs
What is a 24V COB LED Strip Light?
A 24V COB (Chip-on-Board) LED Strip Light is a flexible LED strip that uses closely packed LED chips to produce a smooth, continuous line of light without visible hotspots.
What are the advantages of 24V over 12V LED strips?
24V LED strips experience less voltage drop, making them ideal for longer runs with more consistent brightness. They also require lower current, which can reduce cable size requirements in some installations.
How long can I run a 24V COB LED Strip?
Most 24V COB LED strips can be installed in runs of up to 10 metres before power should be injected or additional strips connected in parallel. Always refer to the product specifications.
Can I cut a 24V COB LED Strip?
Yes. The strip can only be cut at the designated cut marks, which are typically every 50mm on most 24V COB LED strips.
Can I dim a 24V COB LED Strip?
Yes. Simply use a compatible 24V LED dimmer or controller designed for the strip's wattage and voltage.
What power supply do I need?
Use a 24V DC constant voltage LED power supply with a minimum of 20% spare capacity above the total wattage of your LED strip installation.
Can I install the strip outdoors?
Yes, provided you choose a waterproof IP-rated version (such as IP65, IP67, or IP68) and ensure all connectors and power supplies are suitably protected from moisture.
Do I need an aluminium profile?
While not essential, an aluminium LED profile is highly recommended. It improves heat dissipation, protects the strip from damage, and provides a clean, professional finish.
Can I install the strip myself?
Yes. Most DIY users can install a 24V COB LED Strip using the correct power supply and accessories. However, if mains wiring is required, it should be carried out by a qualified electrician.
Can I connect multiple strips together?
Yes. Multiple strips can be connected, but for installations longer than 10 metres, additional strips should be connected in parallel rather than extending one continuous series run.
Why is my LED strip dim at the end?
This is usually caused by voltage drop. The solution is to inject power at additional points or split the installation into multiple parallel runs.
Can I bend the strip around corners?
The strip is flexible but should not be sharply bent, folded, or twisted. Observe the manufacturer's minimum bend radius to avoid damaging the LEDs or circuit board.
How long do COB LED Strip Lights last?
Quality COB LED strips typically have a lifespan of 30,000–50,000 hours, depending on operating conditions, heat management, and power supply quality.
Can I shorten and reconnect the strip?
Yes. After cutting at the marked cut points, the strip can be reconnected using compatible strip connectors or by soldering the connection.
Why choose a 24V COB LED Strip?
24V COB LED strips provide smooth, dot-free illumination, improved efficiency on longer runs, reduced voltage drop, excellent flexibility, and a professional lighting finish, making them ideal for residential, commercial, retail, and architectural lighting projects.
Are LED strip lights waterproof?
LED strip lights are available in different IP ratings to suit both indoor and outdoor applications. Non-waterproof IP20 strips are ideal for indoor use, while waterproof options such as IP65, IP67, and IP68 are designed for outdoor, damp, or exposed environments.
24V COB LED Strip Light FAQs
What is a 24V COB LED Strip Light?
A 24V COB (Chip-on-Board) LED Strip Light is a flexible LED strip that uses closely packed LED chips to produce a smooth, continuous line of light without visible hotspots.
What are the advantages of 24V over 12V LED strips?
24V LED strips experience less voltage drop, making them ideal for longer runs with more consistent brightness. They also require lower current, which can reduce cable size requirements in some installations.
How long can I run a 24V COB LED Strip?
Most 24V COB LED strips can be installed in runs of up to 10 metres before power should be injected or additional strips connected in parallel. Always refer to the product specifications.
Can I cut a 24V COB LED Strip?
Yes. The strip can only be cut at the designated cut marks, which are typically every 50mm on most 24V COB LED strips.
Can I dim a 24V COB LED Strip?
Yes. Simply use a compatible 24V LED dimmer or controller designed for the strip’s wattage and voltage.
What power supply do I need?
Use a 24V DC constant voltage LED power supply with a minimum of 20% spare capacity above the total wattage of your LED strip installation.
Can I install the strip outdoors?
Yes, provided you choose a waterproof IP-rated version (such as IP65, IP67, or IP68) and ensure all connectors and power supplies are suitably protected from moisture.
Do I need an aluminium profile?
While not essential, an aluminium LED profile is highly recommended. It improves heat dissipation, protects the strip from damage, and provides a clean, professional finish.
Can I install the strip myself?
Yes. Most DIY users can install a 24V COB LED Strip using the correct power supply and accessories. However, if mains wiring is required, it should be carried out by a qualified electrician.
Can I connect multiple strips together?
Yes. Multiple strips can be connected, but for installations longer than 10 metres, additional strips should be connected in parallel rather than extending one continuous series run.
Why is my LED strip dim at the end?
This is usually caused by voltage drop. The solution is to inject power at additional points or split the installation into multiple parallel runs.
Can I bend the strip around corners?
The strip is flexible but should not be sharply bent, folded, or twisted. Observe the manufacturer’s minimum bend radius to avoid damaging the LEDs or circuit board.
How long do COB LED Strip Lights last?
Quality COB LED strips typically have a lifespan of 30,000–50,000 hours, depending on operating conditions, heat management, and power supply quality.
Can I shorten and reconnect the strip?
Yes. After cutting at the marked cut points, the strip can be reconnected using compatible strip connectors or by soldering the connection.
Why choose a 24V COB LED Strip?
24V COB LED strips provide smooth, dot-free illumination, improved efficiency on longer runs, reduced voltage drop, excellent flexibility, and a professional lighting finish, making them ideal for residential, commercial, retail, and architectural lighting projects.
Are LED strip lights waterproof?
LED strip lights are available in different IP ratings to suit both indoor and outdoor applications. Non-waterproof IP20 strips are ideal for indoor use, while waterproof options such as IP65, IP67, and IP68 are designed for outdoor, damp, or exposed environments.
Essential Components
Essential Components for a 24V COB LED Strip Light Installation
To ensure a safe, reliable, and long-lasting installation, you'll need the following components:
- 24V DC LED Power Supply – Converts mains power to 24V DC and should be sized with at least 20% spare capacity above the total wattage of the LED strip.
- 24V COB LED Strip Light – Choose the appropriate brightness, colour temperature, length, and IP rating for your application.
- LED Strip Connectors or Soldering Supplies – Used to join strip sections or create custom wiring connections.
- Low-Voltage Cable – Suitable gauge cable for connecting the power supply to the LED strip, especially for longer cable runs.
- Aluminium LED Profile (Recommended) – Provides improved heat dissipation, protects the strip, and creates a professional finish with optional diffuser covers.
- LED Dimmer or Controller (Optional) – Allows brightness adjustment or control of CCT/RGB versions where applicable.
- Mounting Accessories – Clips, brackets, screws, or high-quality double-sided adhesive tape for secure installation.
- Wire Connectors or Terminal Blocks – Ensure safe and reliable electrical connections.
- Heat Shrink Tubing or Insulation – Protects soldered joints and exposed wiring from damage and moisture.
- End Caps and Silicone Sealant (For Waterproof Installations) – Helps maintain the IP rating after cutting or modifying waterproof strips.
Using quality components and correctly sizing the power supply will improve performance, reduce voltage drop, and extend the lifespan of your 24V COB LED Strip Light installation.
Colours & Diagrams
LED strip lights Colour Temperatures
LED strip lights are available in a variety of colour temperatures and colour options, including:
- Warm White (2700K–3000K): Creates a soft, warm ambience ideal for residential and hospitality spaces.
- Natural White (4000K–4500K): Offers a balanced, natural daylight appearance suitable for everyday lighting.
- Cool White (6000K–6500K): Produces a crisp, bright white light ideal for modern and task lighting applications.
LED COB Strip Diagram
Comparison diagram of 12V and 24V COB LED Strip Lights showing their cut intervals and physical dimensions. The 12V strip can be cut every 25mm, while the 24V strip can be cut every 50mm at the designated cut points. Both strips are 8mm wide and approximately 1.6mm thick, providing a slim, flexible profile suitable for a wide range of residential, commercial, and architectural lighting applications. Always cut only at the marked cut lines to ensure proper operation.
Essential Components
Illustration of the essential components for installing a COB LED Strip Light. The image shows a COB LED strip, an aluminium profile channel with diffuser, and the strip's pre-applied 3M double-sided adhesive tape. While the adhesive provides quick installation, an aluminium profile is recommended to improve heat dissipation, protect the LED strip, create a cleaner finish, and maximise the lifespan of the lighting system.
LED COB Strip Light Connection Diagram
24V COB LED Strip Light wiring diagram showing the correct installation method using a 24V DC power supply. Each LED strip run should not exceed 10 meters in series to maintain consistent brightness and minimise voltage drop. For installations longer than 10 meters, connect additional strip lengths in parallel directly to the power supply. This setup ensures even, continuous light output and optimal performance.
Specifications
You may also need...
Related products
Installation & Setup
24V COB LED Strip Light Installation & Setup
Installing a 24V COB LED Strip Light is straightforward when the correct components are used.
Step 1: Plan Your Installation
Measure the installation area, determine the total strip length required, and calculate the total wattage to select a suitable 24V DC power supply with at least 20% spare capacity.
Step 2: Prepare the Mounting Surface
Ensure the surface is clean, dry, and free from dust or grease. For the best performance and longest lifespan, install the strip inside an aluminium LED profile.
Step 3: Cut the Strip (If Required)
Only cut the LED strip at the marked cut points. Cutting elsewhere may damage the strip.
Step 4: Connect the Strip
Connect the strip to the 24V DC power supply using compatible LED strip connectors or by soldering the wires to the copper pads. Always observe the correct polarity (+ and –).
Step 5: Test Before Mounting
Power the strip briefly to confirm all sections illuminate correctly before permanently fixing it in place.
Step 6: Secure the Strip
Remove the adhesive backing and press the strip firmly onto the mounting surface or into the aluminium profile. Avoid excessive bending or twisting during installation.
Step 7: Connect to Power
Connect the power supply to the mains according to local electrical regulations. If you're unsure about mains wiring, consult a qualified electrician.
Installation Tips
- Avoid sharp bends and do not exceed the minimum bend radius.
- Use aluminium profiles to improve heat dissipation and maximise LED lifespan.
- Inject power at multiple points for longer installations to minimise voltage drop.
- Do not power the strip while it is still tightly wound on the reel.
- Choose an IP-rated strip suitable for the installation environment, especially in damp or outdoor locations.
Following these steps will help ensure reliable performance, consistent brightness, and a long service life from your 24V COB LED Strip Light installation.
Troubleshooting & Recommendations
24V COB LED Strip Light Troubleshooting & Recommendations
Common Issues & Solutions
LED strip won't turn on
- Check that the power supply is providing 24V DC.
- Verify all wiring connections and polarity (+ and –).
- Ensure the power supply is switched on and correctly sized for the load.
Strip is dim or unevenly lit
- The power supply may be undersized.
- Excessive voltage drop can occur on long runs—inject power at additional points.
- Check for loose or damaged connections.
Only part of the strip lights up
- Inspect for cuts or damaged sections.
- Ensure connectors are fully seated or solder joints are secure.
- Test the strip in smaller sections to identify the faulty area.
Flickering lights
- Check for loose wiring or poor electrical connections.
- Confirm the power supply is stable and not overloaded.
- Ensure any dimmer or controller is compatible with 24V DC COB LED strips.
Adhesive won't stick
- Clean the mounting surface before installation.
- Install on a smooth, dry surface.
- Use an aluminium LED profile or mounting clips for a more secure, long-term installation.
Recommendations
- Use a quality 24V DC LED power supply with at least 20% spare capacity.
- Install the strip in an aluminium profile to improve heat dissipation, protect the LEDs, and create a professional finish.
- Avoid bending the strip sharply or twisting it during installation.
- Never power the strip while it is still rolled up on the reel, as heat can build up and damage the LEDs.
- For long installations, inject power at multiple points to maintain consistent brightness.
- Select the correct IP rating for your environment—IP20 for indoor dry areas and waterproof versions for damp or outdoor applications.
- Always test the strip before permanently mounting it.
- Disconnect the power before cutting, connecting, or servicing the LED strip.
Following these recommendations will help maximise the performance, efficiency, and lifespan of your 24V COB LED Strip Light while reducing the likelihood of installation issues.
24V COB LED Strip Light Safety Tips
To ensure safe installation and reliable operation, follow these important safety guidelines:
- Always disconnect the power before installing, cutting, or modifying the LED strip.
- Only use a compatible 24V DC LED power supply that is correctly rated for the total wattage of the installation.
- Choose a power supply with at least 20% spare capacity to prevent overloading.
- Observe the correct polarity (+ and –) when making electrical connections.
- Do not connect the LED strip directly to 230V AC mains power.
- Never power the strip while it is tightly wound on the reel, as heat buildup can damage the LEDs.
- Install the strip on a clean, dry, and heat-resistant surface.
- For the best performance and longest lifespan, use an aluminium LED profile to improve heat dissipation.
- Avoid excessive bending, twisting, or folding, and only cut the strip at the designated cut points.
- Keep all electrical connections secure and properly insulated to prevent short circuits.
- Use waterproof (IP-rated) LED strips and sealed connections in damp or outdoor environments.
- Ensure adequate ventilation around the power supply and avoid covering it with insulation or other materials.
- If you're connecting the power supply to mains electricity and are unsure of the wiring, consult a qualified electrician.
- Regularly inspect the installation for loose connections, damaged cables, or signs of overheating.
- Keep LED strips, power supplies, and wiring out of reach of young children and away from flammable materials.
Following these safety precautions will help ensure a safe installation, reliable performance, and a long service life for your 24V COB LED Strip Light.
Fresh Picks
12V SMD LED S-Strip Lights
Original price was: R110.00.R98.00Current price is: R98.00. Vat Incl.
24V COB LED Strip Lights
Original price was: R60.00.R54.00Current price is: R54.00. Vat Incl.
3M Network Cable
Original price was: R70.00.R60.00Current price is: R60.00. Vat Incl.
LED Strip Light 90° Connector (Cooper)
Original price was: R27.00.R24.00Current price is: R24.00. Vat Incl.
10W 230V IP65 Dyce Single Colour SMD Strip Light
Price range: R88.00 through R99.00 Vat Incl.
DYCE Quick Connector with wire 0.5m2
Original price was: R49.00.R44.00Current price is: R44.00. Vat Incl.
24V SMD LED Strip Lights
Original price was: R65.00.R59.00Current price is: R59.00. Vat Incl.
12V SMD LED Strip Lights
Original price was: R112.00.R100.00Current price is: R100.00. Vat Incl.
12V SMD LED Strip Lights 12V
Original price was: R77.00.R70.00Current price is: R70.00. Vat Incl.
12V Driver | Power Supply | Transformer | 150 Watt | 2 Year Warranty
Original price was: R718.00.R606.00Current price is: R606.00. Vat Incl.
