LED Module – 2 Chip / 160° / 1.0W / 12V / 9000K – 11 000K / Ice White / 5 Year warranty
Deliveries
- FREE Deliveries to all Signage Companies in S.A
Where can I be used…
Channel letters and backlit signs, Retail displays and exhibition stands, Cabinet and under-shelf lighting
Fabricated Letters and Light Boxes (50-150mm deep)
Why use me?
High brightness output with low 1W power draw for efficient performance
Two high-intensity LEDs provide strong, even light spread
Compact and robust design suitable for medium-sized signage and displays
Online Price:
Original price was: R12.00.R11.00Current price is: R11.00. Vat Incl.
936 in stock (can be backordered)
Product Details
Specifications
| Input | 12 Volt DC |
| Power | 1 Watt |
| Current | 0.083A |
| Lumens | 94 Lumens |
| Colour Temp | 9000K-11000K |
| Qty LED Chips | 2 (2835 Chip) |
| Viewing Angle | 160° Angle |
| Dimensions | 42mm x 18.5 x 9.7mm |
| Mounting | 3M VHB Double Sided Tape or screw mount |
| Wire Length | 100mm |
| Max Ambient Temp | 60° C |
| Waterproofing | (IP67) |
| Warranty | 5 Years |
| Max Module | 20 Modules Per String in Series |
| Datasheet |  |
Do's and Donts
Do’s
Do power with a regulated 12V DC supply
Do mount on clean surfaces to ensure adhesive strength
Do space modules appropriately for even lighting
Don’ts
Don’t overload the circuit with too many modules
Don’t install in wet areas unless waterproof-rated
Don’t twist or over-bend wires during installation
Colour Chart
Basic Diagram & Checklist
Bulk Pricing
